STATUS: stable Implementing optional argument lists. More...

#include "definitions.h"
#include "slist.h"
#include <stdarg.h>

This graph shows which files directly or indirectly include this file:

Data Structures
struct	OptArg
	An optional Argument. More...
struct	OptArgList
	A list of optional Arguments. More...
Defines
#define	NO_OPTARGS NULL
#define	optarg_PARSE_PTR(opts, label, var, type, tmp)
	Check and assign a void-ptr from OptArgList. Suppose you got optargs in a function and want to check for variable "distfct" of type "DistFct",.
#define	optarg_PARSE_SCALAR(opts, label, var, type, tmp)
	Check and assign a scalar from OptArgList. Suppose you got optargs in a function and want to check for variable "seed" of type "unsigned long",.
Functions
OptArg *	optarg_ptr (const char key, void ptr)
	create a new OptArg* containing a pointer.
OptArg *	optarg_scalar (const char *key, double scalar)
	create a new OptArg* containing a scalar value.
OptArgList *	optarglist (char *format,...)
	Creates an OptArgList out of one or many arguments.
OptArgList *	optarglist_append_arg (OptArgList list, OptArg arg)
	create a new optarglist that is the former optarglist with the new arg appended.
OptArgList *	optarglist_delete_arg (OptArgList list, OptArg arg)
	delete an argument from the argument list.
void	optarglist_free (OptArgList *list)
	free an optarglist.
bool	optarglist_has_key (OptArgList list, const char key)
	return TRUE if key is found in list, else FALSE.
OptArg *	optarglist_optarg_by_key (OptArgList list, const char key)
	Return a pointer to an OptArg struct with the key from the list.
void	optarglist_print (OptArgList list, FILE out)
	print an optarglist.
void *	optarglist_ptr_by_key (OptArgList list, const char key)
	Return a pointer to the data_ptr field of the OptArg struct.
OptArgList *	optarglist_remove_freeflag (OptArgList list, bool removedflag)
	remove the optarglist_free-flag from the list.
double	optarglist_scalar_by_key (OptArgList list, const char key)
	Return the value of the scalar argument.
OptArgList *	optarglisttmp (char *format,...)
	Creates an OptArgList including a optarglist_free arg.

Detailed Description

STATUS: stable Implementing optional argument lists.

This feature can be used to conveniently pass arguments to functions. This makes sense for generic functions that take one or more function pointers requiring different arguements each.

The syntax is as follows:

 double *mydata = read_data();
 OptArgList *args = optarglist( "bottom_frequency=double,num_trials=int,data=double*",
                                0.5, 10, mydata );
 function_taking_optargs( args );
 free_optarglist( args ) // does not free any mydata

Temporary Optional Argument lists

Every function that receives an optarglist is required to check for the existence of "optarglist_free" within the parameterlist. If this parameter exists, the function is required to free the memory pointed to the argument. Also, the parameter is removed from the list and possibly passed to other functions.

This enables the use of optarglists like this:

 function_taking_optargs( optarglist( "bottom_frequency=double,
                                       num_trials=int,
                                                    data=double*,
                                                    optarglist_free=int",
                                                    0.5, 10, mydata, 1) );

or even shorter like

 function_taking_optargs( optarglisttmp( "bottom_frequency=double,
                                        num_trials=int,
                                                     data=double*",
                                                    0.5, 10, mydata) );

where the memory deallocation is handled by the called function.

For writing a function that takes an OptArgList* as an argument.

The function optarlist_remove_freeflag() removes the optarglist_free-flag from the list and returns a new list without the flag. The old list is free'd in case that the optarglist_free argument is found.

The removedflag-flag is set to FALSE if it is the same list, to TRUE if it is a new (truncated) list.

Usage is as follows:

     void testfct( OptArgList *opts ){
        // overwrite the pointer
         bool freeflag_removed=FALSE;
        opts=optarglist_remove_freeflag( opts, &freeflag_removed );

         // do some stuff including passing the argument to some other function
         call_other_function( opts );

         // clean up in case the flag was indeed removed
         if( freeflag_removed )
            optarglist_free( opts );
     }

Definition in file optarg.h.

Define Documentation

#define NO_OPTARGS NULL

Definition at line 96 of file optarg.h.

#define optarg_PARSE_PTR	(	opts,
		label,
		var,
		type,
		tmp
	)

Value:

if( optarglist_has_key( (opts), (label) ) ){                    \
     (tmp) = optarglist_ptr_by_key( (opts), (label) );          \
     if( (tmp) ) (var)=(type)(tmp);                                 \
  }

Check and assign a void-ptr from OptArgList. Suppose you got optargs in a function and want to check for variable "distfct" of type "DistFct",.

        void *ptr; // tmp
        DistFct distf;
        optarg_PARSE_PTR( optargs, "distfct", distf, DistFct, ptr );

Definition at line 143 of file optarg.h.

#define optarg_PARSE_SCALAR	(	opts,
		label,
		var,
		type,
		tmp
	)

Value:

if( optarglist_has_key( (opts), (label) ) ){                    \
     (tmp) = optarglist_scalar_by_key( (opts), (label) );       \
     if( !isnan( (tmp) ) ) (var)=(type)(tmp);                       \
  }

Check and assign a scalar from OptArgList. Suppose you got optargs in a function and want to check for variable "seed" of type "unsigned long",.

        double x; // tmp
        unsigned long seed;
        optarg_PARSE_SCALAR( optargs, "seed", seed, unsigned long, x );

Definition at line 128 of file optarg.h.

Function Documentation

OptArg* optarg_ptr	(	const char *	key,
		void *	ptr
	)

create a new OptArg* containing a pointer.

Definition at line 414 of file optarg.c.

OptArg* optarg_scalar	(	const char *	key,
		double	scalar
	)

create a new OptArg* containing a scalar value.

Definition at line 402 of file optarg.c.

OptArgList* optarglist	(	char *	format,
			...
	)

Creates an OptArgList out of one or many arguments.

The Format string has the following convention:

	 key1=double*,key2=void*,key3=int,key=double,...

If you have at least one asterisk (*) in the specification, then the corresponding argument needs to be a pointer. Internally, all pointer types are void* and stored along with the given specification.

Be VERY careful to typecast all variables to match the type you indicated. For example, if you have a float-variable and pass it as double, you need to typecast to (double).

Only "basic" scalar values (without asterisk) are supported:

char
short
int
long
float
double

Blanks/Newlines etc are stripped from key and type, so

	 key = double , key2=void*

are ok.

Definition at line 218 of file optarg.c.

OptArgList* optarglist_append_arg	(	OptArgList *	list,
		OptArg *	arg
	)

create a new optarglist that is the former optarglist with the new arg appended.

The caller is responsible for freeing the old list.

Parameters:

list

the pointer to the Optarglist

Returns:: the new list (the caller is responsible for freeing the old one)

Definition at line 307 of file optarg.c.

OptArgList* optarglist_delete_arg	(	OptArgList *	list,
		OptArg *	arg
	)

delete an argument from the argument list.

The function returns a new OptArgList containing which is the old list minus the argument. The arguments copied!

The caller is responsible for freeing the old list.

Parameters:

	list	the list
	arg	the argument to delete

Returns:: the new list (the caller is responsible for freeing the old one)

Definition at line 330 of file optarg.c.

void optarglist_free ( OptArgList * list )

free an optarglist.

does not free any data_ptr.

Definition at line 231 of file optarg.c.

bool optarglist_has_key	(	OptArgList *	list,
		const char *	key
	)

return TRUE if key is found in list, else FALSE.

Definition at line 290 of file optarg.c.

OptArg* optarglist_optarg_by_key	(	OptArgList *	list,
		const char *	key
	)

Return a pointer to an OptArg struct with the key from the list.

NULL if no such key has been found.

Definition at line 278 of file optarg.c.

void optarglist_print	(	OptArgList *	list,
		FILE *	out
	)

print an optarglist.

Definition at line 28 of file optarg.c.

void* optarglist_ptr_by_key	(	OptArgList *	list,
		const char *	key
	)

Return a pointer to the data_ptr field of the OptArg struct.

with the key from the list. NULL if no such key has been found.

Definition at line 262 of file optarg.c.

OptArgList* optarglist_remove_freeflag	(	OptArgList *	list,
		bool *	removedflag
	)

remove the optarglist_free-flag from the list.

This function is only interesting for you, if you want to write an own function that takes an OptArgList* as an argument.

The function removes the optarglist_free-flag from the list and returns a new list without the flag. The old list is free'd in case that the optarglist_free argument is found.

The removedflag-flag is set to FALSE if it is the same list, to TRUE if it is a new (truncated) list.

Usage is as follows:

     void testfct( OptArgList *opts ){
        // overwrite the pointer
         bool freeflag_removed=FALSE;
        opts=optarglist_remove_freeflag( opts, &freeflag_removed );

         // do some stuff including passing the argument to some other function
         call_other_function( opts );

         // clean up in case the flag was indeed removed
         if( freeflag_removed )
            optarglist_free( opts );

Parameters:

	list	the list
	removedflag	is set to FALSE if it is the same list, to TRUE if it is a new (truncated) list.

Returns:: a pointer to the new (or the old) list

Definition at line 386 of file optarg.c.

double optarglist_scalar_by_key	(	OptArgList *	list,
		const char *	key
	)

Return the value of the scalar argument.

or NaN if not available. Check returned value with isnan()!

Definition at line 242 of file optarg.c.

OptArgList* optarglisttmp	(	char *	format,
			...
	)

Creates an OptArgList including a optarglist_free arg.

The Format string has the following convention:

	 key1=double*,key2=void*,key3=int,key=double,...

If you have at least one asterisk (*) in the specification, then the corresponding argument needs to be a pointer. Internally, all pointer types are void* and stored along with the given specification.

Be VERY careful to typecast all variables to match the type you indicated. For example, if you have a float-variable and pass it as double, you need to typecast to (double).

Only "basic" scalar values (without asterisk) are supported:

char
short
int
long
float
double

Blanks/Newlines etc are stripped from key and type, so

	 key = double , key2=void*

are ok.

Definition at line 167 of file optarg.c.
