src/eeg.h File Reference

STATUS: stable EEG struct handling functions More...

#include "definitions.h"
#include <string.h>
#include <stdlib.h>
#include "chaninfo.h"
#include "array.h"
#include "slist.h"

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Data Structures
struct	EEG
	a complete EEG-data set with meta-inforation. More...
struct	MarkerType
	describe a type of time-marker. More...
Defines
#define	EEG_CLONE_ALL   0
	clone everything
#define	EEG_CLONE_NOCHANINFO   2<<3
	clone everything except the eeg->chaninfo field
#define	EEG_CLONE_NODATA   2<<1
	clone everything except the eeg->data field
#define	EEG_CLONE_NOMARKERS   2<<2
	clone everything except the eeg->markers, eeg->nmarkers eeg->marker_labels fields
Functions
void	eeg_append_comment (EEG *eeg, const char *comment)
	append text to the comment-field in the EEG-struct.
EEG *	eeg_clone (const EEG *eeg, int flags)
EEG *	eeg_extract_channels (EEG *eeg, const int *channels, int nchannels, bool alloc)
EEG *	eeg_extract_trials (EEG *eeg, const int *trials, int ntrials, bool alloc)
void	eeg_free (EEG *eeg)
	free's all memory in EEG-struct. including the data
EEG *	eeg_init (int nbchan, int ntrials, int nsamples)
	create an empty EEG-data struct.
EEG *	eeg_init_markers (int nmarkers_per_trial, EEG *eeg)
void	eeg_print (FILE *out, const EEG *eeg, int preview)
	Pretty-print an EEG - struct.
char *	eeg_sprint (char *out, const EEG *eeg, int preview)
void	print_channelinfo (FILE *out, const ChannelInfo *c)

---

Detailed Description

STATUS: stable EEG struct handling functions

Definition in file eeg.h.

---

Define Documentation

#define EEG_CLONE_ALL   0

clone everything

Definition at line 86 of file eeg.h.

#define EEG_CLONE_NOCHANINFO   2<<3

clone everything except the eeg->chaninfo field

Definition at line 92 of file eeg.h.

#define EEG_CLONE_NODATA   2<<1

clone everything except the eeg->data field

Definition at line 87 of file eeg.h.

#define EEG_CLONE_NOMARKERS   2<<2

clone everything except the eeg->markers, eeg->nmarkers eeg->marker_labels fields

Definition at line 89 of file eeg.h.

---

Function Documentation

void eeg_append_comment	(	EEG *	eeg,
		const char *	comment
	)

append text to the comment-field in the EEG-struct.

Parameters:

	eeg	the input struct
	comment	the text to append

Definition at line 62 of file eeg.c.

EEG* eeg_clone	(	const EEG *	eeg,
		int	flags
	)

EEG* eeg_extract_channels	(	EEG *	eeg,
		const int *	channels,
		int	nchannels,
		bool	alloc
	)

EEG* eeg_extract_trials	(	EEG *	eeg,
		const int *	trials,
		int	ntrials,
		bool	alloc
	)

void eeg_free

(

EEG *

eeg

)

free's all memory in EEG-struct. including the data

Parameters:

eeg

Definition at line 43 of file eeg.c.

EEG* eeg_init	(	int	nbchan,
		int	ntrials,
		int	nsamples
	)

create an empty EEG-data struct.

Parameters:

	nbchan	number of channels
	ntrials	number of trials (1 for continuous data)
	nsamples	number of samples for each trial

Returns:

EEG

Definition at line 12 of file eeg.c.

EEG* eeg_init_markers	(	int	nmarkers_per_trial,
		EEG *	eeg
	)

void eeg_print	(	FILE *	out,
		const EEG *	eeg,
		int	preview
	)

Pretty-print an EEG - struct.

Parameters:

	out	the output stream
	eeg	the struct
	preview	number of items to preview in data

Definition at line 77 of file eeg.c.

char* eeg_sprint	(	char *	out,
		const EEG *	eeg,
		int	preview
	)

void print_channelinfo	(	FILE *	out,
		const ChannelInfo *	c
	)

Definition at line 524 of file eeg.c.
