src/array.h File Reference

STATUS: work in progress Numerical Arrays. More...

#include "definitions.h"
#include "mathadd.h"
This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Data Structures

struct  Array
 Numerical Array struct. More...

Defines

#define DIM_COLS   1
#define DIM_ROWS   0



#define array_SIZEOF_DTYPE(size, dtype)
 get size of datatype.
#define array_DTYPESTRING(dtstring, dtype)
 convert datatype to a string representation.
#define array_NUMEL(a)   ( ((a)->nbytes)/((a)->dtype_size) )
 get number of elements in array.
#define array_DTYPEPRINT(out, dtype, mem)
 Print an array-datatype.
#define array_MEMSET(mem, dtype, val)
 set the memory mem to value of type dtype.
#define array_INDEX1(array, dtype, i1)
 fast 1D array indexing typecasting to C-type.
#define array_INDEX2(array, dtype, i1, i2)
 fast 2D array indexing typecasting to C-type.
#define array_INDEX3(array, dtype, i1, i2, i3)
 fast 3D array indexing typecasting to C-type.
#define array_INDEXMEM1(array, i1)
 fast 1D array indexing returning a void pointer.
#define array_INDEXMEM2(array, i1, i2)
 fast 2D array indexing returning a void pointer.
#define array_INDEXMEM3(array, i1, i2, i3)
 fast 3D array indexing returning a void pointer.
enum  DType {
  CHAR = 0, UINT, INT, LONG,
  ULONG, FLOAT, DOUBLE
}


Data-types for Array struct.

More...
Arrayarray_new (DType dtype, uint ndim, const uint *dims)
 Initialize new array struct.
Arrayarray_new2 (DType dtype, uint ndim,...)
 Initialize new array struct.
Arrayarray_fromptr (DType dtype, uint ndim, void *data, const uint *size)
 Initialize new array struct.
Arrayarray_fromptr2 (DType dtype, uint ndim, void *data,...)
 Initialize new array struct.
Arrayarray_new_dummy (DType dtype, uint ndim,...)
 create array that is filled with values from 1 to n over all dimensions.
Arrayarray_randunif (unsigned long seed, uint ndim,...)
 create array that is filled with random values from [0, ..., 1].
bool array_comparable (const Array *a, const Array *b)
 Compare two array's dimensions and datatype.
Arrayarray_copy (const Array *in, bool allocdata)
 makes a copy of an array.
void array_free (Array *a)
 free all memory associated with the array.
void array_shuffle (Array *a, unsigned long seed)
 shuffle the entries of an array.
void array_typecast (Array *a, DType target_type)
 Array-typecast.
void * array_index (const Array *a, uint *idx)
 Index the array.
void * array_index2 (const Array *a,...)
 Index the array.
Arrayarray_slice (const Array *a, const char *slicedesc)
 Extract sub-arrays from array.
Arrayarray_concatenate (const Array *a, const Array *b, int dim)
 concatenate two arrays.
int array_scale (Array *a, double x)
 multiply all entries in array with x.
void array_reverse (Array *a)
 Reverse order of elements in a (in-place).
int array_dimred (Array *a)
 Delete unnecessary dimensions (of size 1).
void * array_max (const Array *a)
 Get maximum element from array.
void * array_min (const Array *a)
 Get minimum element from array.
Arrayarray_convert_rowcolmajor (Array *a, bool alloc)
 convert a row-major array to col-major.
void array_calc_colindex (ulong idx, const uint *size, uint nsize, uint *index)
 calculate the column-major index-tuple given the offset from element 0.
void array_calc_rowindex (ulong idx, const uint *size, uint nsize, uint *index)
 calculate the row-major index-tuple given the offset from element 0.
void array_print (Array *a, uint nel_per_dim, FILE *out)
 print an array.
void array_dtype_to_double (double *out, void *mem, DType dt)
 cast memory of type dt in location mem to double.

Detailed Description

STATUS: work in progress Numerical Arrays.

This is an efficient implementation of a numerical array of

The library provides some convenient functionality:

Arbitrary Dimensions and Types

Note:
in applications you almost always know the type/dimensionality of your array. This section is for you only if you want to write functions that operate on arrays of arbitrary dimension and/or type.

In principle, an Array struct can hold n-dimensional arrays of any type implemented in DType. All functions starting with the prefix array_*() operate on arbitrary dimensions and types.

Arbitrary types

Working with arbitray types requires some sophistication if it is conducted at runtime.

To read elements in the array where you don't know the type, you can convert the element to double using array_dtype_to_double()

 // void   array_dtype_to_double( double *out, void *mem, DType dt );
 void *mem = array_index( a, 3, 4 ); // access element (3,4)
 double el;
 array_dtype_to_double( &el, mem, a->dtype );
 // work with el

To write elements in the array of unknown type, you can use the macro array_MEMSET()

 // #define array_MEMSET( mem, dtype, val )
 void *mem = array_index( a, 3, 4 ); // access element (3,4)
 array_MEMSET( mem, a->dtype, 3 ); // set element to 3 (value is casted)

Arbitrary dimension

To write functions that operate on arbitrary dimensions is either very simple (if the operation you want to apply is the same for all elements) or very complicated.

If you want to apply a per-element operation on all elements in the array, you can simply loop over them:

 Array *a=get_array_from_somewhere();
 long i, n = array_NUMEL( a ); // number of elements
 double *mem;
 for( i=0; i<n; i++ ){
    mem=&array_INDEX1( a, double, i ); // if you know the type
     // ...
     // operate on *mem
     // ...
 }

Vectors and Matrices

However, for numerical work, it is in most cases sufficient to operate on floating point numbers. Therefore, 1D and 2D Array structs of DType DOUBLE are used to represent vectors and matrices, respectively. I.e. that each function starting with matrix_*( Array m ) accepts only 2D Arrays of DType DOUBLE functions starting with vector_*( Array *m ) accept only 1D Arrays of DType DOUBLE. This is checked with the Macros matrix_CHECK() and vector_CHECK(). See also linalg.h .

Convenient Indexing

Indexing the n-dimensional array can be done via two routes:

Slicing Array Objects

It is often necessary to get parts of arrays for computation. Inspired by slicing in MATLAB, a string representing the slice is composed as follows:

Note:
indexing assumes c-like indices (i.e. from 0 to n-1)
you need to provide all dimensions

Examples:

 // 3D-array
 Array *a = array_new( DOUBLE, 3, 10, 11, 12 );

 // Here b is a new 3D-array containing all elements in the first dimension,
 // the first 4 in the second and elements 1,2,3 in the third.
 Array *b = array_slice( a, ":,0-3,[1 2 3]");

 // c is a 2D array
 Array *c = array_slice( a, ":,:,1");

 // d is a 1D array
 Array *d = array_slice( a, ":,3,1");

Data Ownership

Depending on how you initialize and Array, the struct takes over responsibility to free the array->data pointer or not. This is implemented using the array->free_data flag. Some functions take a 'alloc'-flag which indicates whether memory is shared or not. Usually, the 'parent'-array has the resonsibility then.

Note:
in practice, you hardly have to care about data-ownership. If you simply call array_free() on all arrays in your code you should be fine.

Definition in file array.h.


Define Documentation

#define DIM_COLS   1

Definition at line 161 of file array.h.

#define DIM_ROWS   0

Definition at line 160 of file array.h.
